The Monarch H-535 Atomizing Water Nozzle is a precision-engineered industrial spray nozzle designed to generate a thin, high-velocity spray sheet for efficient cleaning and liquid application processes.

The nozzle features a simple one-piece construction incorporating a specially machined V-notch flow channel and an oval discharge orifice. This design creates a flat fan spray pattern with excellent impact force and uniform liquid distribution across the spray width.

Due to its high spray velocity, the H-535 is widely used in applications where strong cleaning action, surface washing, rinsing, and liquid coverage are required. It is particularly effective in automatic car wash systems, commercial dishwashers, industrial cleaning equipment, and process spray installations.

Available in various capacities and spray angles from 30° to 90°, the nozzle can be selected to suit a wide range of industrial requirements.

Key Features

High-velocity flat spray nozzle

One-piece precision construction

V-notch milling and oval orifice design

Produces a thin cutting spray sheet

Excellent cleaning and washing performance

Available in multiple spray angles

Uniform liquid distribution

Durable brass and stainless steel construction

Reliable industrial operation

Applications

Automatic car wash systems

Commercial dishwashers

Industrial washing systems

Surface cleaning equipment

Rinsing applications

Process spraying systems

Industrial liquid distribution

General cleaning operations

Why Choose This Nozzle

Produces powerful high-impact spray performance

Ideal for cleaning and washing applications

Simple one-piece design for reliability

Wide range of capacities and spray angles available

Durable construction for long service life

Trusted Monarch spray nozzle technology

Technical Description

The Monarch H-535 utilizes a specially designed V-notch flow passage and oval discharge orifice to create a thin flat spray pattern with high liquid velocity.

This spray configuration delivers excellent surface coverage while maintaining strong impact force for cleaning and rinsing applications. The one-piece construction minimizes maintenance requirements and ensures consistent spray performance.

The nozzle is available in multiple capacities and spray angles, allowing system designers to optimize coverage, flow rate, and cleaning effectiveness for specific industrial applications.

Technical Specifications
